WCRT 200 RT Wrapper
A fully automatic rotary arm stretch wrapping system designed for high-speed pallet load containment in conveyorized packaging environments.
The machine utilizes a rotating arm wrapping design that keeps the pallet load stationary during operation, improving wrapping stability for heavy, lightweight, or unstable loads while maximizing throughput and wrapping consistency. Ideal for facilities requiring reliable automated pallet wrapping with continuous conveyor flow and high production capacity.
This automatic rotary arm stretch wrapper is engineered to wrap palletized loads using a rotating arm system where the film carriage rotates around a stationary pallet load. By eliminating pallet rotation during the wrapping cycle, the system improves load stability and allows consistent wrapping performance for heavy, tall, or unstable pallet loads.
Designed for demanding automated packaging operations, the machine combines powered pre-stretch film technology, advanced Allen-Bradley controls, automated film tail treatment, and integrated conveyor handling to provide high-speed wrapping performance with minimal operator intervention. Its heavy-duty structural steel construction and industrial-grade rotary arm design support continuous-duty operation and long-term reliability.
- Machine type: Fully automatic rotary arm stretch wrapper
- Production capacity: Up to approximately 100 loads per hour
- Machine dimensions: Approximately 144 in. L × 148 in. W × 140 in. H
- Maximum load size: Approximately 48 in. L × 48 in. W × 80 in. H
- Maximum load weight: Approximately 5,000 lbs standard, 6,000 lbs optional
- Approximate shipping weight: Approximately 4,500 lbs
- Electrical requirements: 230V / 3 Phase / 60 Hz / 20A
- Pneumatic requirements: Approximately 3 CFM @ 80 PSI
- Rotary arm speed: Variable up to approximately 17 RPM standard with optional speeds up to 35 RPM
- Conveyor speed: Up to approximately 35 FPM
- Conveyor pass height: Approximately 18 in. standard
- Conveyor roller diameter: Approximately 2.5 in.
- Conveyor frame width: Approximately 52 in. between frame rails
- Film carriage: 20 in. NO-THREAD® powered pre-stretch carriage standard
- Film pre-stretch ratio: Approximately 50% to 300% standard with capability up to 400% depending on film type
- Rotary arm drive: 1 HP AC motor with variable frequency drive
- Conveyor drive: 1 HP 230VAC motor with variable frequency drive
- Film carriage drive: 1 HP AC motor with variable frequency drive
- Rotary arm bearing: Approximately 25 in. heavy-duty ring gear bearing with pinion gear drive
- Control system: Allen-Bradley CompactLogix PLC with OptixPanel touchscreen
- Wrap selections: Separate top and bottom wrap counts adjustable from 0–9
- Available wrap arm diameter extensions: Approximately 92 in., 104 in., and 116 in.
- Available wrap height extensions: Approximately 92 in., 104 in., and 116 in.
- Structure: Free-standing heavy-duty structural steel frame with integrated mounting legs
(Final specifications vary depending on machine configuration, conveyor layout, film type, and selected options.)
- Fully automatic rotary arm stretch wrapper
- Up to approximately 100 loads per hour production capacity
- Stationary load wrapping operation for improved load stability
- NO-THREAD® powered pre-stretch film carriage
- Automatic film clamp and cut system
- Electronic film tension and force-to-load control
- Allen-Bradley CompactLogix PLC controls
- Allen-Bradley OptixPanel touchscreen HMI
- Remote connectivity through integrated Ethernet communication
- Counterbalanced rotary arm design
- Dynamic braking system for rotary arm control
- Automated remote lubrication station
- Heavy-duty conveyor integration
- Independent conveyor forward/reverse controls
- Advanced operator safety monitoring system with multiple photoeyes
- Safety fencing with electronically interlocked access door
- Optional top platen, roping, washdown, and cold temperature packages available
- Designed for continuous high-speed industrial operation
The system utilizes a counterbalanced rotary wrapping arm that rotates around the stationary pallet load while a powered film carriage travels vertically to apply stretch film throughout the wrap cycle. Because the load remains fixed in position, the machine can handle unstable or heavy pallet loads more effectively than traditional turntable wrapping systems.
Its NO-THREAD® powered pre-stretch carriage significantly reduces film consumption by stretching film prior to application while maintaining proper containment force on the load. Electronic film tension controls automatically adjust film force according to load profile and wrapping requirements, improving wrapping consistency and reducing film breakage.
The machine incorporates automated film clamping, cutting, and tail treatment systems that eliminate loose film tails and improve final pallet appearance. Integrated diagnostics, remote connectivity, soft-start rotary arm control, independent conveyor controls, and multiple safety monitoring devices further improve operational efficiency and simplify maintenance.
Heavy-duty conveyor integration, rotary arm dynamic braking, automated lubrication systems, and reinforced steel boom construction provide smooth high-speed operation while minimizing maintenance requirements and extending equipment life.
This automatic rotary arm stretch wrapper is engineered to wrap palletized loads using a rotating arm system where the film carriage rotates around a stationary pallet load. By eliminating pallet rotation during the wrapping cycle, the system improves load stability and allows consistent wrapping performance for heavy, tall, or unstable pallet loads.
Designed for demanding automated packaging operations, the machine combines powered pre-stretch film technology, advanced Allen-Bradley controls, automated film tail treatment, and integrated conveyor handling to provide high-speed wrapping performance with minimal operator intervention. Its heavy-duty structural steel construction and industrial-grade rotary arm design support continuous-duty operation and long-term reliability.
The system utilizes a counterbalanced rotary wrapping arm that rotates around the stationary pallet load while a powered film carriage travels vertically to apply stretch film throughout the wrap cycle. Because the load remains fixed in position, the machine can handle unstable or heavy pallet loads more effectively than traditional turntable wrapping systems.
Its NO-THREAD® powered pre-stretch carriage significantly reduces film consumption by stretching film prior to application while maintaining proper containment force on the load. Electronic film tension controls automatically adjust film force according to load profile and wrapping requirements, improving wrapping consistency and reducing film breakage.
The machine incorporates automated film clamping, cutting, and tail treatment systems that eliminate loose film tails and improve final pallet appearance. Integrated diagnostics, remote connectivity, soft-start rotary arm control, independent conveyor controls, and multiple safety monitoring devices further improve operational efficiency and simplify maintenance.
Heavy-duty conveyor integration, rotary arm dynamic braking, automated lubrication systems, and reinforced steel boom construction provide smooth high-speed operation while minimizing maintenance requirements and extending equipment life.
- Fully automatic rotary arm stretch wrapper
- Up to approximately 100 loads per hour production capacity
- Stationary load wrapping operation for improved load stability
- NO-THREAD® powered pre-stretch film carriage
- Automatic film clamp and cut system
- Electronic film tension and force-to-load control
- Allen-Bradley CompactLogix PLC controls
- Allen-Bradley OptixPanel touchscreen HMI
- Remote connectivity through integrated Ethernet communication
- Counterbalanced rotary arm design
- Dynamic braking system for rotary arm control
- Automated remote lubrication station
- Heavy-duty conveyor integration
- Independent conveyor forward/reverse controls
- Advanced operator safety monitoring system with multiple photoeyes
- Safety fencing with electronically interlocked access door
- Optional top platen, roping, washdown, and cold temperature packages available
- Designed for continuous high-speed industrial operation
- Machine type: Fully automatic rotary arm stretch wrapper
- Production capacity: Up to approximately 100 loads per hour
- Machine dimensions: Approximately 144 in. L × 148 in. W × 140 in. H
- Maximum load size: Approximately 48 in. L × 48 in. W × 80 in. H
- Maximum load weight: Approximately 5,000 lbs standard, 6,000 lbs optional
- Approximate shipping weight: Approximately 4,500 lbs
- Electrical requirements: 230V / 3 Phase / 60 Hz / 20A
- Pneumatic requirements: Approximately 3 CFM @ 80 PSI
- Rotary arm speed: Variable up to approximately 17 RPM standard with optional speeds up to 35 RPM
- Conveyor speed: Up to approximately 35 FPM
- Conveyor pass height: Approximately 18 in. standard
- Conveyor roller diameter: Approximately 2.5 in.
- Conveyor frame width: Approximately 52 in. between frame rails
- Film carriage: 20 in. NO-THREAD® powered pre-stretch carriage standard
- Film pre-stretch ratio: Approximately 50% to 300% standard with capability up to 400% depending on film type
- Rotary arm drive: 1 HP AC motor with variable frequency drive
- Conveyor drive: 1 HP 230VAC motor with variable frequency drive
- Film carriage drive: 1 HP AC motor with variable frequency drive
- Rotary arm bearing: Approximately 25 in. heavy-duty ring gear bearing with pinion gear drive
- Control system: Allen-Bradley CompactLogix PLC with OptixPanel touchscreen
- Wrap selections: Separate top and bottom wrap counts adjustable from 0–9
- Available wrap arm diameter extensions: Approximately 92 in., 104 in., and 116 in.
- Available wrap height extensions: Approximately 92 in., 104 in., and 116 in.
- Structure: Free-standing heavy-duty structural steel frame with integrated mounting legs
(Final specifications vary depending on machine configuration, conveyor layout, film type, and selected options.)
