SML 150 TT Wrapper
A semi-automatic turntable stretch wrapper designed to provide reliable pallet load containment and operator-friendly wrapping performance for a wide range of industrial packaging applications.
The system combines heavy-duty steel construction, powered pre-stretch film delivery, and advanced operator controls to improve load stability while reducing film consumption. Ideal for warehouses, manufacturing facilities, and distribution operations requiring dependable semi-automatic pallet wrapping.
This semi-automatic stretch wrapping system is engineered to wrap palletized loads using a rotating turntable design paired with a vertically traveling film carriage. The machine is built for continuous industrial operation and provides consistent load containment while minimizing film waste through powered pre-stretch film technology.
Designed for flexibility and durability, the wrapper accommodates a broad range of pallet sizes, load weights, and packaging requirements while maintaining smooth and controlled wrapping cycles. Its rugged structural steel construction and Allen-Bradley control platform provide dependable long-term performance in demanding production environments.
- Machine type: Semi-automatic turntable stretch wrapper
- Production capacity: Up to approximately 55 loads per hour
- Machine dimensions: Approximately 118 in. L × 59 in. W × 86.5 in. H
- Maximum load weight: Approximately 4,000 lbs
- Turntable diameter: Approximately 58 in.
- Turntable plate thickness: Approximately 3/8 in. steel plate
- Turntable speed: Variable speed up to approximately 16 RPM
- Turntable drive: 1 HP AC motor with variable frequency drive
- Film carriage: 20 in. NO-THREAD® powered pre-stretch carriage standard
- Film pre-stretch ratio: Approximately 50% to 300% standard with capability up to 400% depending on film type
- Film carriage drive: 1 HP AC motor with variable frequency drive
- Electrical requirements: 120V / 1 Phase / 60 Hz / 15A
- Control system: Allen-Bradley Micro800 PLC with 24V controls
- Construction: Heavy-duty structural steel frame with 14 gauge formed steel tower
- Shipping weight: Approximately 2,200 lbs
- Available wrap height extensions: Approximately 92 in., 104 in., 116 in., and 128 in.
- Applications: Warehousing, manufacturing, logistics, food processing, and industrial packaging operations
(Final specifications vary depending on machine configuration, load dimensions, film type, and selected options.)
- Semi-automatic turntable stretch wrapper
- Up to approximately 55 loads per hour production rate
- Powered NO-THREAD® pre-stretch film carriage
- Electronic film tension control system
- Variable speed turntable and carriage operation
- Automatic load height sensing photoeye
- Reinforced wrap cycle capability
- Soft start and soft stop turntable control
- Heavy-duty structural steel construction
- Allen-Bradley PLC control system
- Forklift portable base design
- Ramp accessible from three sides
- Film roping capability available
- Multiple wrap height extension options available
- Optional scales, top platen, and washdown configurations available
- Low-maintenance industrial wrapping design
The system utilizes a powered rotating turntable combined with a motorized film carriage that applies stretch film vertically around the pallet load during the wrapping cycle. Variable speed controls allow operators to adjust both carriage and turntable speeds to optimize wrapping performance for varying product types and load configurations.
Its NO-THREAD® powered pre-stretch carriage significantly reduces film usage while maintaining proper load containment force. Electronic film tension controls automatically regulate film force during operation, improving wrapping consistency while minimizing film breaks and load distortion.
The machine incorporates an automatic load height sensing photoeye, reinforced wrap controls, top and bottom wrap selectors, and soft-start turntable control to improve operator convenience and load protection. Optional accessories including top platens, scales, roping systems, ramps, washdown configurations, and extended wrap heights allow the machine to be customized for specialized applications and operating environments.
This semi-automatic stretch wrapping system is engineered to wrap palletized loads using a rotating turntable design paired with a vertically traveling film carriage. The machine is built for continuous industrial operation and provides consistent load containment while minimizing film waste through powered pre-stretch film technology.
Designed for flexibility and durability, the wrapper accommodates a broad range of pallet sizes, load weights, and packaging requirements while maintaining smooth and controlled wrapping cycles. Its rugged structural steel construction and Allen-Bradley control platform provide dependable long-term performance in demanding production environments.
The system utilizes a powered rotating turntable combined with a motorized film carriage that applies stretch film vertically around the pallet load during the wrapping cycle. Variable speed controls allow operators to adjust both carriage and turntable speeds to optimize wrapping performance for varying product types and load configurations.
Its NO-THREAD® powered pre-stretch carriage significantly reduces film usage while maintaining proper load containment force. Electronic film tension controls automatically regulate film force during operation, improving wrapping consistency while minimizing film breaks and load distortion.
The machine incorporates an automatic load height sensing photoeye, reinforced wrap controls, top and bottom wrap selectors, and soft-start turntable control to improve operator convenience and load protection. Optional accessories including top platens, scales, roping systems, ramps, washdown configurations, and extended wrap heights allow the machine to be customized for specialized applications and operating environments.
- Semi-automatic turntable stretch wrapper
- Up to approximately 55 loads per hour production rate
- Powered NO-THREAD® pre-stretch film carriage
- Electronic film tension control system
- Variable speed turntable and carriage operation
- Automatic load height sensing photoeye
- Reinforced wrap cycle capability
- Soft start and soft stop turntable control
- Heavy-duty structural steel construction
- Allen-Bradley PLC control system
- Forklift portable base design
- Ramp accessible from three sides
- Film roping capability available
- Multiple wrap height extension options available
- Optional scales, top platen, and washdown configurations available
- Low-maintenance industrial wrapping design
- Machine type: Semi-automatic turntable stretch wrapper
- Production capacity: Up to approximately 55 loads per hour
- Machine dimensions: Approximately 118 in. L × 59 in. W × 86.5 in. H
- Maximum load weight: Approximately 4,000 lbs
- Turntable diameter: Approximately 58 in.
- Turntable plate thickness: Approximately 3/8 in. steel plate
- Turntable speed: Variable speed up to approximately 16 RPM
- Turntable drive: 1 HP AC motor with variable frequency drive
- Film carriage: 20 in. NO-THREAD® powered pre-stretch carriage standard
- Film pre-stretch ratio: Approximately 50% to 300% standard with capability up to 400% depending on film type
- Film carriage drive: 1 HP AC motor with variable frequency drive
- Electrical requirements: 120V / 1 Phase / 60 Hz / 15A
- Control system: Allen-Bradley Micro800 PLC with 24V controls
- Construction: Heavy-duty structural steel frame with 14 gauge formed steel tower
- Shipping weight: Approximately 2,200 lbs
- Available wrap height extensions: Approximately 92 in., 104 in., 116 in., and 128 in.
- Applications: Warehousing, manufacturing, logistics, food processing, and industrial packaging operations
(Final specifications vary depending on machine configuration, load dimensions, film type, and selected options.)
