Pallet Dispenser
Pallet Dispensers are heavy-duty automated systems designed to efficiently dispense individual empty pallets into conveyor-based material handling operations.
By automating pallet feeding, the system helps reduce manual pallet handling, minimize forklift traffic, and improve production efficiency throughout palletizing and packaging lines. Built for continuous-duty industrial operation, the rugged structural design provides reliable performance for a wide variety of pallet handling applications.
Pallet Dispensers are designed to automatically separate and dispense individual empty pallets from a stacked magazine into downstream conveyor systems. The system delivers a controlled supply of pallets to robotic palletizers, conventional palletizers, stretch wrappers, and other automated material handling equipment while reducing operator intervention and improving workflow efficiency.
The heavy-duty design incorporates a welded structural steel frame, hydraulic lift system, and integrated conveyor to provide dependable pallet dispensing and long service life. Multiple configurations are available to accommodate varying pallet sizes, conveyor layouts, and facility requirements while integrating seamlessly into new or existing pallet handling systems.
- Automated empty pallet dispensing system
- Dispenses one pallet at a time
- Handles wood and plastic pallets
- Heavy-duty welded structural steel construction
- Electrically driven hydraulic lift table
- Pneumatically operated pallet holding fingers
- Integrated dual-chain conveyor
- Automatic and manual operating modes
- 90° and 180° loading configurations available
- Factory wired and tested controls
- Reduces manual pallet handling and forklift traffic
- Multiple conveyor lengths and elevations available
- Optional VFD drive motors available
- Custom paint finishes available
- Equipment Type: Automated pallet dispenser
- Product Types: Empty wood or plastic pallets
- Magazine Capacity: Approximately 13 pallets
- Magazine Height: Approximately 8'
- Conveyor Type: Integrated dual-chain conveyor
- Conveyor Extension: Approximately 2'-6" beyond frame
- Conveyor Elevation: Approximately 18" top of chain
- Lift System: Electrically driven hydraulic lift table
- Pallet Retention: Pneumatically operated holding fingers
- Construction: Welded structural steel frame with heavy-gauge enclosure panels
- Controls: PLC-controlled automatic and manual operation
- Loading Orientation: 90° or 180°
- Finish: Industrial painted frame with safety guards
- Optional Features: Extended conveyors, custom elevations, VFD motors, and custom paint colors
(Final specifications vary depending on pallet dimensions, pallet styles, throughput requirements, and overall system configuration.)
The pallet dispenser utilizes an electrically driven hydraulic lift table and pneumatically operated pallet holding fingers to automatically position and release one empty pallet at a time onto the integrated conveyor. Once a pallet is discharged, the lift automatically indexes the remaining pallet stack into position for the next dispensing cycle, providing a continuous supply of pallets to downstream equipment.
Designed for continuous industrial operation, the welded structural steel frame and heavy-gauge enclosure panels provide exceptional durability in demanding manufacturing and warehouse environments. Standard magazine configurations accommodate approximately 15 empty pallets, while multiple loading orientations, conveyor lengths, elevations, and drive options allow the system to be customized for specific application requirements.
Integrated PLC controls provide automatic and manual operating modes while supporting communication with upstream and downstream automation equipment. The modular design allows the pallet dispenser to be incorporated into automated pallet conveyor systems with minimal installation time and maximum operational flexibility.
Pallet Dispensers are designed to automatically separate and dispense individual empty pallets from a stacked magazine into downstream conveyor systems. The system delivers a controlled supply of pallets to robotic palletizers, conventional palletizers, stretch wrappers, and other automated material handling equipment while reducing operator intervention and improving workflow efficiency.
The heavy-duty design incorporates a welded structural steel frame, hydraulic lift system, and integrated conveyor to provide dependable pallet dispensing and long service life. Multiple configurations are available to accommodate varying pallet sizes, conveyor layouts, and facility requirements while integrating seamlessly into new or existing pallet handling systems.
The pallet dispenser utilizes an electrically driven hydraulic lift table and pneumatically operated pallet holding fingers to automatically position and release one empty pallet at a time onto the integrated conveyor. Once a pallet is discharged, the lift automatically indexes the remaining pallet stack into position for the next dispensing cycle, providing a continuous supply of pallets to downstream equipment.
Designed for continuous industrial operation, the welded structural steel frame and heavy-gauge enclosure panels provide exceptional durability in demanding manufacturing and warehouse environments. Standard magazine configurations accommodate approximately 15 empty pallets, while multiple loading orientations, conveyor lengths, elevations, and drive options allow the system to be customized for specific application requirements.
Integrated PLC controls provide automatic and manual operating modes while supporting communication with upstream and downstream automation equipment. The modular design allows the pallet dispenser to be incorporated into automated pallet conveyor systems with minimal installation time and maximum operational flexibility.
- Equipment Type: Automated pallet dispenser
- Product Types: Empty wood or plastic pallets
- Magazine Capacity: Approximately 13 pallets
- Magazine Height: Approximately 8'
- Conveyor Type: Integrated dual-chain conveyor
- Conveyor Extension: Approximately 2'-6" beyond frame
- Conveyor Elevation: Approximately 18" top of chain
- Lift System: Electrically driven hydraulic lift table
- Pallet Retention: Pneumatically operated holding fingers
- Construction: Welded structural steel frame with heavy-gauge enclosure panels
- Controls: PLC-controlled automatic and manual operation
- Loading Orientation: 90° or 180°
- Finish: Industrial painted frame with safety guards
- Optional Features: Extended conveyors, custom elevations, VFD motors, and custom paint colors
(Final specifications vary depending on pallet dimensions, pallet styles, throughput requirements, and overall system configuration.)
- Automated empty pallet dispensing system
- Dispenses one pallet at a time
- Handles wood and plastic pallets
- Heavy-duty welded structural steel construction
- Electrically driven hydraulic lift table
- Pneumatically operated pallet holding fingers
- Integrated dual-chain conveyor
- Automatic and manual operating modes
- 90° and 180° loading configurations available
- Factory wired and tested controls
- Reduces manual pallet handling and forklift traffic
- Multiple conveyor lengths and elevations available
- Optional VFD drive motors available
- Custom paint finishes available
