Motor Driven Roller MDR
A motorized roller conveyor system designed to provide quiet, energy-efficient, and non-contact zero pressure accumulation for cartons, totes, and packaged products.
The conveyor utilizes run-on-demand conveyor zones to minimize energy consumption while maintaining smooth and controlled product flow. Ideal for automated packaging, distribution, and material handling applications requiring reliable accumulation and low-maintenance operation.
This motorized roller conveyor system is engineered to provide high-speed product transport and zero pressure accumulation using independently controlled conveyor zones. Products accumulate without touching, preventing skewing, side-by-side product conditions, and product jams while maintaining smooth and predictable conveyor flow.
Designed for automated packaging and distribution environments, the conveyor can simultaneously handle mixed product types including cartons, totes, and slave pallets even when there are significant weight differences between products. Its modular construction and quiet operation make it well suited for facilities requiring efficient product accumulation and low operational noise levels.
- Conveyor type: Motorized roller accumulation conveyor
- Conveyor frame: 6 in. deep × 10 gauge conveyor frame
- Accumulation zone lengths: Approximately 24 in. or 36 in.
- Roller diameter: Approximately 1.875 in.
- Roller construction: 16 gauge galvanized rollers
- Drive system: 24VDC brushless motor driven roller
- Conveyor speeds available: Approximately 148 ft/min and 197 ft/min
- Conveyor operation: Run-on-demand zero pressure accumulation
- Product sensing: Side-mounted polarized retro-reflective photo-eye sensors
- Control cards: ERSC accumulation card and EZ24 drive card
- Finish: Conductive light gray powder-coated finish
- Applications: Packaging, accumulation, palletizing, warehouse, and distribution systems
(Final specifications vary depending on conveyor layout, product dimensions, throughput requirements, and system configuration.)
- Motorized roller conveyor technology
- Non-contact zero pressure accumulation
- Run-on-demand conveyor zones for reduced energy consumption
- Quiet low-noise conveyor operation
- Handles cartons, totes, slave pallets, and packaged products
- Prevents product bumping, skewing, and jams
- Independently controlled accumulation zones
- High-speed conveyor performance
- Low-maintenance brushless motor driven rollers
- Photo-eye controlled product sensing
- Conductive powder-coated frame to reduce static build-up
- Modular conveyor design for flexible layouts and future expansion
- Compatible with automated packaging and material handling systems
The system utilizes 24VDC motorized drive rollers controlled through independently activated accumulation zones. Each conveyor zone only runs when needed to advance product, reducing unnecessary conveyor operation while lowering energy consumption, conveyor wear, and overall facility noise levels.
Products accumulate without contact using photo-eye controlled zone management that precisely controls carton release and spacing throughout the conveyor line. This non-contact accumulation method helps prevent product damage while improving conveyor efficiency and downstream equipment performance.
Its conductive powder-coated frame and specially designed conductive axle isolators help minimize static build-up, reduce operational noise, and improve long-term conveyor durability. The modular conveyor architecture allows the system to integrate into packaging, sortation, palletizing, warehouse, and distribution conveyor systems.
This motorized roller conveyor system is engineered to provide high-speed product transport and zero pressure accumulation using independently controlled conveyor zones. Products accumulate without touching, preventing skewing, side-by-side product conditions, and product jams while maintaining smooth and predictable conveyor flow.
Designed for automated packaging and distribution environments, the conveyor can simultaneously handle mixed product types including cartons, totes, and slave pallets even when there are significant weight differences between products. Its modular construction and quiet operation make it well suited for facilities requiring efficient product accumulation and low operational noise levels.
The system utilizes 24VDC motorized drive rollers controlled through independently activated accumulation zones. Each conveyor zone only runs when needed to advance product, reducing unnecessary conveyor operation while lowering energy consumption, conveyor wear, and overall facility noise levels.
Products accumulate without contact using photo-eye controlled zone management that precisely controls carton release and spacing throughout the conveyor line. This non-contact accumulation method helps prevent product damage while improving conveyor efficiency and downstream equipment performance.
Its conductive powder-coated frame and specially designed conductive axle isolators help minimize static build-up, reduce operational noise, and improve long-term conveyor durability. The modular conveyor architecture allows the system to integrate into packaging, sortation, palletizing, warehouse, and distribution conveyor systems.
- Motorized roller conveyor technology
- Non-contact zero pressure accumulation
- Run-on-demand conveyor zones for reduced energy consumption
- Quiet low-noise conveyor operation
- Handles cartons, totes, slave pallets, and packaged products
- Prevents product bumping, skewing, and jams
- Independently controlled accumulation zones
- High-speed conveyor performance
- Low-maintenance brushless motor driven rollers
- Photo-eye controlled product sensing
- Conductive powder-coated frame to reduce static build-up
- Modular conveyor design for flexible layouts and future expansion
- Compatible with automated packaging and material handling systems
- Conveyor type: Motorized roller accumulation conveyor
- Conveyor frame: 6 in. deep × 10 gauge conveyor frame
- Accumulation zone lengths: Approximately 24 in. or 36 in.
- Roller diameter: Approximately 1.875 in.
- Roller construction: 16 gauge galvanized rollers
- Drive system: 24VDC brushless motor driven roller
- Conveyor speeds available: Approximately 148 ft/min and 197 ft/min
- Conveyor operation: Run-on-demand zero pressure accumulation
- Product sensing: Side-mounted polarized retro-reflective photo-eye sensors
- Control cards: ERSC accumulation card and EZ24 drive card
- Finish: Conductive light gray powder-coated finish
- Applications: Packaging, accumulation, palletizing, warehouse, and distribution systems
(Final specifications vary depending on conveyor layout, product dimensions, throughput requirements, and system configuration.)
