Bag Packer HS
The Bag Packer 25 is a high-speed automatic drop case packer designed to gently collate and load bags into corrugated shipping cases.
Utilizing controlled gravity-assisted product placement, the system delivers reliable case packing while maintaining bag integrity at production rates up to approximately 90 bags per minute. Its flexible design accommodates multiple bag sizes, case formats, and packing patterns, making it an ideal solution for high-volume packaging operations.
The Bag Packer 25 automatically receives bags from upstream packaging equipment, organizes them into the required packing pattern, and precisely drops them into shipping cases. The system is designed to maximize throughput while maintaining consistent product orientation and minimizing product handling throughout the packing process.
Its modular design allows the machine to accommodate multiple case sizes, bag configurations, and production layouts with quick recipe changes through an intuitive operator interface. Intelligent conveyor management and automated case handling reduce operator involvement while improving overall line efficiency and packaging consistency.
- Equipment Type: Automatic drop bag case packer
- Product Types: Poly bags, paper bags, mesh bags, and flexible packages
- Reference Case Size: Approximately 23.6" × 15.7" (600 × 400 mm)
- Optional Case Size: Approximately 15.7" × 11.8" (400 × 300 mm)
- Maximum Case Load: Up to approximately 50 lbs
- Throughput: Up to approximately 90 bags per minute
- Product Entry: Configurable conveyor entry direction
- Case Handling: Automatic case dispensing and full case discharge
- Controls: PLC with color touchscreen HMI
- Recipe Management: Adjustable recipes, timers, speeds, and counters
- Connectivity: Ethernet/LAN with remote support capability
- Construction: Precision laser-cut and welded steel frame
- Finish: Polyurethane, epoxy, galvanized, and stainless steel components as required
- Energy Management: Intelligent Energy Efficiency (IEE)
- Safety Features: Integrated guarding with risk-assessed machine design
- Optional Features: Additional case size kits and customized packing configurations
(Final specifications vary depending on bag dimensions, case sizes, throughput requirements, and overall system configuration.)
- High-speed automatic drop case packing
- Controlled gravity product placement
- Production rates up to approximately 90 bags per minute
- Handles a wide variety of bag sizes and case formats
- Configurable product and case entry directions
- Automatic case dispensing
- Intelligent upstream product management
- Simple touchscreen recipe management
- Proprietary packing pattern creation software
- Reverse layer function for improved pallet stability
- Intelligent Energy Efficiency (IEE) operation
- PLC-controlled automation system
- Ethernet/LAN connectivity
- Remote diagnostics and support capability
- Heavy-duty welded steel construction
- Designed for continuous-duty industrial operation
The Bag Packer 25 utilizes intelligent product accumulation and collation conveyors to organize incoming bags into the desired packing configuration before gently releasing the completed pattern into the waiting case. Configurable product entry directions and proprietary pattern creation software allow operators to quickly create and modify packing recipes while minimizing changeover time.
To improve shipping stability, the system includes a reverse layer function that automatically alternates bag orientation between layers when required. Automatic case dispensing, full case discharge, and integrated conveyor management further streamline production while reducing manual handling.
Designed for continuous industrial operation, the machine is manufactured from laser-cut and precision-machined steel components with heavy-duty welded construction. Intelligent Energy Efficiency (IEE) technology minimizes power consumption by allowing conveyor drives to operate only when product is present, reducing overall energy usage while maintaining maximum production capacity.
The Bag Packer 25 automatically receives bags from upstream packaging equipment, organizes them into the required packing pattern, and precisely drops them into shipping cases. The system is designed to maximize throughput while maintaining consistent product orientation and minimizing product handling throughout the packing process.
Its modular design allows the machine to accommodate multiple case sizes, bag configurations, and production layouts with quick recipe changes through an intuitive operator interface. Intelligent conveyor management and automated case handling reduce operator involvement while improving overall line efficiency and packaging consistency.
The Bag Packer 25 utilizes intelligent product accumulation and collation conveyors to organize incoming bags into the desired packing configuration before gently releasing the completed pattern into the waiting case. Configurable product entry directions and proprietary pattern creation software allow operators to quickly create and modify packing recipes while minimizing changeover time.
To improve shipping stability, the system includes a reverse layer function that automatically alternates bag orientation between layers when required. Automatic case dispensing, full case discharge, and integrated conveyor management further streamline production while reducing manual handling.
Designed for continuous industrial operation, the machine is manufactured from laser-cut and precision-machined steel components with heavy-duty welded construction. Intelligent Energy Efficiency (IEE) technology minimizes power consumption by allowing conveyor drives to operate only when product is present, reducing overall energy usage while maintaining maximum production capacity.
- High-speed automatic drop case packing
- Controlled gravity product placement
- Production rates up to approximately 90 bags per minute
- Handles a wide variety of bag sizes and case formats
- Configurable product and case entry directions
- Automatic case dispensing
- Intelligent upstream product management
- Simple touchscreen recipe management
- Proprietary packing pattern creation software
- Reverse layer function for improved pallet stability
- Intelligent Energy Efficiency (IEE) operation
- PLC-controlled automation system
- Ethernet/LAN connectivity
- Remote diagnostics and support capability
- Heavy-duty welded steel construction
- Designed for continuous-duty industrial operation
- Equipment Type: Automatic drop bag case packer
- Product Types: Poly bags, paper bags, mesh bags, and flexible packages
- Reference Case Size: Approximately 23.6" × 15.7" (600 × 400 mm)
- Optional Case Size: Approximately 15.7" × 11.8" (400 × 300 mm)
- Maximum Case Load: Up to approximately 50 lbs
- Throughput: Up to approximately 90 bags per minute
- Product Entry: Configurable conveyor entry direction
- Case Handling: Automatic case dispensing and full case discharge
- Controls: PLC with color touchscreen HMI
- Recipe Management: Adjustable recipes, timers, speeds, and counters
- Connectivity: Ethernet/LAN with remote support capability
- Construction: Precision laser-cut and welded steel frame
- Finish: Polyurethane, epoxy, galvanized, and stainless steel components as required
- Energy Management: Intelligent Energy Efficiency (IEE)
- Safety Features: Integrated guarding with risk-assessed machine design
- Optional Features: Additional case size kits and customized packing configurations
(Final specifications vary depending on bag dimensions, case sizes, throughput requirements, and overall system configuration.)
