Agropal R2
A high-performance bag palletizing system designed specifically for products with challenging stacking characteristics that require additional load stabilization during pallet formation.
The system combines controlled layer formation, synchronized compression mechanisms, and automatic pallet size adjustment to create stable, uniform pallet loads. Ideal for operations handling multiple bag styles and weights while maintaining consistent pallet quality and production efficiency.
This bag palletizer is engineered to safely and accurately palletize products that may be difficult to stack using conventional palletizing methods. The system utilizes a controlled layer-forming process that organizes products within an adjustable mold structure before depositing completed layers onto the pallet.
Designed to automatically adapt to varying pallet widths, the palletizer provides flexibility while maintaining precise product placement and load stability. Its combination of synchronized handling components, adjustable positioning systems, and controlled compression technology helps create secure pallet loads while minimizing product shifting throughout the palletizing process.
- System type: Bag palletizer
- Production rate: Approximately 12–18 operations per minute
- Product weight range: Approximately 5.5–110 lbs
- Maximum pallet height: Approximately 104 in.
- Product formats: Paper bags, plastic bags, raffia bags, and jute bags
- Conveyor type: Beehive-style rough-top belt conveyor
- Layer formation: Adjustable chute-based layer forming system
- Compression system: Synchronized lateral compression devices
- Mold system: Pneumatic opening mold with pneumatic-mechanical closure
- Pallet handling: Integrated lifting platform and pallet extraction rollers
- Pallet width adjustment: Automatic adaptation to varying pallet dimensions
- Production capacity: Designed for approximately 1,000 palletizing movements per day
(Final specifications vary depending on product dimensions, throughput requirements, pallet patterns, and system configuration.)
- Bag palletizing system
- Designed for difficult-to-stack products
- Handles paper, plastic, raffia, and jute bags
- Vertical product discharge into pre-layer formation zone
- Synchronized opening clamps and lateral compression system
- Adjustable layer-forming chutes
- Automatic adaptation to varying pallet widths
- Pneumatic mold opening and closure system
- Integrated lifting platform
- Pallet extraction rollers
- Rough-top belt conveyor infeed
- Controlled layer formation process
- Stable pallet load creation
- High-precision product positioning
- Continuous production operation
Products enter the palletizer through a specially designed rough-top belt conveyor that provides secure product handling and controlled transfer into the layer-forming section. Products are discharged vertically into a pre-layer zone where synchronized positioning systems align and prepare each layer prior to pallet placement.
The palletizer incorporates synchronized opening clamps and lateral compression mechanisms that help maintain product alignment during layer formation. Adjustable chutes automatically modify layer dimensions to accommodate varying product sizes while ensuring consistent layer quality and pallet patterns.
Once the layer is formed, the products are positioned within a mold assembly featuring frontal and lateral opening capabilities. Pneumatic-mechanical mold controls maintain layer integrity during transfer, while an integrated lifting platform and pallet extraction roller system support smooth pallet building and discharge operations.
This bag palletizer is engineered to safely and accurately palletize products that may be difficult to stack using conventional palletizing methods. The system utilizes a controlled layer-forming process that organizes products within an adjustable mold structure before depositing completed layers onto the pallet.
Designed to automatically adapt to varying pallet widths, the palletizer provides flexibility while maintaining precise product placement and load stability. Its combination of synchronized handling components, adjustable positioning systems, and controlled compression technology helps create secure pallet loads while minimizing product shifting throughout the palletizing process.
Products enter the palletizer through a specially designed rough-top belt conveyor that provides secure product handling and controlled transfer into the layer-forming section. Products are discharged vertically into a pre-layer zone where synchronized positioning systems align and prepare each layer prior to pallet placement.
The palletizer incorporates synchronized opening clamps and lateral compression mechanisms that help maintain product alignment during layer formation. Adjustable chutes automatically modify layer dimensions to accommodate varying product sizes while ensuring consistent layer quality and pallet patterns.
Once the layer is formed, the products are positioned within a mold assembly featuring frontal and lateral opening capabilities. Pneumatic-mechanical mold controls maintain layer integrity during transfer, while an integrated lifting platform and pallet extraction roller system support smooth pallet building and discharge operations.
- Bag palletizing system
- Designed for difficult-to-stack products
- Handles paper, plastic, raffia, and jute bags
- Vertical product discharge into pre-layer formation zone
- Synchronized opening clamps and lateral compression system
- Adjustable layer-forming chutes
- Automatic adaptation to varying pallet widths
- Pneumatic mold opening and closure system
- Integrated lifting platform
- Pallet extraction rollers
- Rough-top belt conveyor infeed
- Controlled layer formation process
- Stable pallet load creation
- High-precision product positioning
- Continuous production operation
- System type: Bag palletizer
- Production rate: Approximately 12–18 operations per minute
- Product weight range: Approximately 5.5–110 lbs
- Maximum pallet height: Approximately 104 in.
- Product formats: Paper bags, plastic bags, raffia bags, and jute bags
- Conveyor type: Beehive-style rough-top belt conveyor
- Layer formation: Adjustable chute-based layer forming system
- Compression system: Synchronized lateral compression devices
- Mold system: Pneumatic opening mold with pneumatic-mechanical closure
- Pallet handling: Integrated lifting platform and pallet extraction rollers
- Pallet width adjustment: Automatic adaptation to varying pallet dimensions
- Production capacity: Designed for approximately 1,000 palletizing movements per day
(Final specifications vary depending on product dimensions, throughput requirements, pallet patterns, and system configuration.)
